Facilities List

Lavelle Medical operates a 30,000-square-foot, FDA-registered, ISO 13485-certified medical device manufacturing facility in Westford, MA, equipped with advanced machinery and technology. Our comprehensive machining, finishing, and quality control capabilities make Lavelle Medical a turnkey provider for all of your medical device machining needs.

EQUIPMENT LIST

  • 1 – Zeiss CMM Spectrum 5/5/6 VAST XXT with Calypso software
  • 1 – Hexagon Global S Green 5.5.5 CMM
  • 5 – Deltronic DH-16 Profile Comparators
  • 1 – Keyence IM-7030T Optical Measuring System
  • 1 – Keyence IM-6225 Optical Measuring System
  • 1 – Sprint Ram Optical 200 Vision System
  • 1 – Vision Precision Engineering Optical Dyna-Scope 100X
  • 4 – Brown & Sharpe Micro-height units
  • 12 – Surface Plates
  • 12 – Nikon Microscopes 50X
  • 2 – Federal Profilometers
  • 1 – Phase 2 Rockwell Material Hardness Analysis System
  • 2 – Sunnen Precision Bore Gages
  • 1 – Citizen L20 Type X With High Pressure through Coolant with Thread Whirling Capability
  • 1 – Citizen M420V – 9 Axis with Thread Whirling Capability
  • 1 – Citizen M20 12 w/ Thread Whirling Capabilities
  • 1 – Nakamura AS-200 with Y-Axis and Live Tooling
  • 1 – Nakamura TMC-18 with Live Tooling
  • 1 – Nakamura TW-10 Y twin spindle w/ live tooling
  • 1 – Nakamura SC-250 With Live Tooling

All Machining Centers Have Robotic Loading Capabilities Using Our Universal UR10 Robots

  • 1 – Brother US00Xd-1, 5 axis horizontal machining center robotic load system
  • 5 – Fanuc RoboDrills-T21 with 4th axis capability
  • 2 – Fanuc RoboDrills-D21 with pallet changers
  • 1 – Feeler HV-800 DM with 4th axis capability
  • 1 – Feeler MV-1000H Vertical Machine Center
  • 3 – CNC Haas Indexing Units
  • 7 – Fanuc ā€œCā€ series Wire EDM Machines w/4th Axis
  • 1 – Ocean 500 Technology CNC Hole Popper
  • 1 – Hurco-VM-1 Machining Center
  • 1 – ProtoTRAK SLX CNC lathe
  • 1 – ProtoTRAK DMP2 3-axis CNC lathe
  • 3 – Bridgeports, w/ precision digital readout systems
  • 3 – Precision Hardinge Tool Room Lathes Precision Read Outs
  • 1 – Proto-Lab, Rigid 400 3D printing system
  • 2 – FOBA M2000P Laser Marking systems with 4th Axis and UDI Capability with Robotic Loading
  • 1 – Electrox 600 Laser Marking System with 4th Axis and UDI capability, with Robotic Loading
  • 1 – OR Laser Technology ECO 4600 Laser Welding System with full Rotary Capabilities
  • 1 – OR Laser Technology ECO 3300 Laser Welding system with full rotary capabilities
  • 3 – Calibrated heat treat ovens and Cress heat treat oven
  • 1 – KC AX Horizon auto feed cutoff saw
  • 1 – V500 Vertical cutoff saw
  • 1 – Harig precision surface grinder 6ā€ x 18ā€
  • 1 – Agathon precision tool grinder
  • 1 – Sunnen Honing machine
  • 1 – Crest ultrasonic cleaning system model OCJ-1218
  • 1 – Crest ultrasonic passivation line
  • 3 – Precision glass bead stations
  • 2 – Vibratory tumbler stations
  • 1 – Pelton & Crane sterilizer model AF 10

ISO 9001, ISO 13485, FDA and ITAR Certified
